American DJ Element HEXIP Pearl Par Lighting Effect

The American DJ Element HexIP Pearl is a par can lighting effect that is IP54 outdoor rated, powered via rechargeable battery and comes in a super-durable white metal enclosure that protects the lighting effect against the elements. The Element HEXIP Pearl is ideal for fixed and mobile applications thanks to its compact design and excellent features and makes an excellent addition to any lighting engineer’s arsenal. This lighting effect is perfect for mobile entertainers, music venues, live events, club and bar venues, festivals, outdoor events, garden parties, schools and colleges, and theatres.

The Element HexIP Pearl comes fitted with six super-bright 10w LEDs that give you RGBAW+UV colours that allow you to achieve a broad range of various colours, hues, and tones that are sure to amaze your audience and is perfect for stage washing. This lighting effect comes with five operational modes consisting of auto-run mode which offers 16 colour change and fade modes and one colour/fade combo mode. Also available is a sound-activated mode which dances to the beat of your music thanks to an integrated microphone, static colour mode, RGBAW+UV dimmer mode, and DMX control mode which enables you to create your own customised light shows using the five DMX channel modes.

This lighting effect comes housed in a pearl white enclosure that is super-durable and weather resistant making it ideal for garden parties and outdoor events. There is an integrated kickstand that enables you to angle the effect while it’s on the floor so you can shine the light exactly where it is needed most. The rear of the Element HexIP features a water-resistant hatch, when opened you get access to the LED display menu with four menu buttons that let you navigate your way around the various settings and functions this effect has to offer.

• 4 x 10-Watt RGBAW+UV LEDs (6-in-1 - Red, Green, Blue, Amber, White & UV)
• Life expectancy: rated at 50,000 hrs.
• IP54 Outdoor Rated
• Built-in kickstand to angle figure while it’s on the floor
• 4-button DMX menu display on rear panel with water resistant hatch
• Built-in WiFLY EXR wireless DMX: Up to 2,500 feet (760M) when used with ADJ’s WiFLY EXR Battery Transceiver
• 64 built-in Color Macros
• Variable RGBAW+UV color mixing offers a smooth, seemingly unlimited color palette - Great for Stage or Wall Washing!
• LED pulse and strobe effect (0.2Hz-11Hz)
• Flicker Free Operation
• Electronic Dimming: 0 - 100% with 5 dimming curves
• Run all night – No duty cycle
• Energy Saving Mode

Optical

• 4 x 10-Watt RGBAW+UV LEDs (6-in-1 - Red, Green, Blue, Amber, White & UV)
• Life expectancy: rated at 50,000 hrs.
• LUX: 684 @ 2M; 171 @ 4M
• Beam angle: 20-degree
• PWM frequency:1000Hz

Connection

• DMX: WiFLY EXR Wireless DMX
• IEC connection to power/charge fixture

Control

• Control protocol: WiFLY EXR DMX
• 5 DMX Channel modes: 6, 7, 8, 11, or 12
• Remote control: WiFLY EXR DMX, UC-IR, Airstream IR
• 5 Operational modes: RGBAW+UV Dimmer Mode; Sound Active mode; Auto Run Mode (16 colour change modes, 16 colour fade modes, & 1 colour/fade combo mode); Static Colour mode; and DMX Controlled

Battery

• Battery Type: fixed lithium battery
• Battery Energy: 73.26WH (Watt Hours)
• Battery Weight: 0.42 kg.
• Battery Voltage: 11.1V
• Battery Capacity: 6.6AH
• Total Lithium Ion Cells: 9 pieces
• Battery Wrap Material: PVC sleeving + highland barley paper
• Battery Charge Time: 4.5 Hours (With POWER switch On)
• Battery Life: 11 hours (single colour)

Electrical

• Power Draw Total (All LED's @ Full On): 45W, 0.5A @ 120V/60Hz, 42W, 0.2A @ 220V/50Hz,
• Multi-voltage operation: AC 100-240V, 50/60Hz

Dimensions / Weight

• Dimensions (LxWxH): 140 x 140 x 140mm
• Weight: 2.9kg.

Certifications

• CE Approved
• IP54 Outdoor rated
