American DJ PAR ZP100 3k LED Par Can Lighting Effect

American DJ PAR ZP100 3k LED Par Can Lighting Effect

Regular price £281.00
Regular price Sale price £281.00
Sale Sold out
Tax included. Shipping calculated at checkout.
Check your eligibility

Fast check - won't affect your credit rating.

American DJ

View full details

The American DJ Par ZP100 3K gives you a modern LED twist to the usual halogen Par Can lighting effects and is powered by a potent 100w warm white LED that features a colour temperature of 3000K. This par can light effect works brilliantly for both fixed and mobile applications and is suited towards mobile entertainers, live events, music venues, club and bar venues, festivals, theatres, and schools and colleges.

The Par ZP100 3K comes equipped with a 100w warm white COB (chip on board) LED which features a colour temperature of 3000k and provides you with an output that is comparable to a 1000w halogen sealed beam par. This lighting effect is also supplied with five different beam angle options that can be changed by hand and allows you to achieve a variety of different beam angles. The rear of this lighting fixture is equipped with powerCON in/output connections that enable the light to be daisy-chained while a 5-pin DMX in/output gives you the ability to create your own customised light shows and offers a variable strobe rate alongside five different dimming curve options. The effect is housed in a traditional Par Can enclosure made of polished silver aluminium.

The Par ZP100 3K gives lighting and stage designers the look and feel of a traditional stage par can with all the technological advances of modern day LED lighting. These advantages include low power draw, the effect and your performers won’t overheat under the light, as well as DMX control over dimming and strobe functions. This fixture also includes a gel frame that enables you to insert various diffusion filters to further change the beam angle of the lights colour.

  • 4-button DMX menu display on rear panel
  • Adjustable latch to manually change beam angle
  • Includes gel frame for diffusion filters (Diffusion filter sold separately)
  • Strobe effect (25Hz max)
  • Flicker Free Operation
  • Electronic Dimming: 0 - 100% with 5 dimming curves
  • Run all night – No duty cycle
  • Silver polished aluminum exterior housing

Optical

  • 100 Watt COB Warm White LED (3000K)
  • Life expectancy: rated at 50,000 hrs.
  • LUX: 7135 (9˚); 4440 (15˚); 2236 (20˚); 1266 (25˚); 812 (30˚)
  • CRI: 90
  • Beam angle: 9, 15, 20, 25 0r 30-degree (manual adjustment)
  • PWM frequency:1200Hz

Connection

  • DMX: 5-pin DMX In/Out
  • powerCON In/Out to power battery or daisy chain fixture

Control

  • Control protocol: DMX-512
  • 2 DMX Channels

Electrical

  • Power Draw Total (All LED's @ Full On): 115W, 0.964A @ 120V/60Hz, 112W, 0.5A @ 220V/50Hz
  • Multi-voltage operation: AC 100-240V, 50/60Hz
  • Daisy chain: 15 fixtures (120V); 25 fixtures (230V)

Dimensions / Weight

  • Dimensions (LxWxH mm): 491 x 272 x 273
  • Weight: 3.4kg.
