American DJ Vizi CMY300 Moving Head Lighting Effect

American DJ Vizi CMY300 Moving Head Lighting Effect

Regular price £3,215.00
Regular price Sale price £3,215.00
Sale Sold out
Tax included. Shipping calculated at checkout.
Check your eligibility

Fast check - won't affect your credit rating.

American DJ

View full details

The ADJ Vizi CMY300 is a next-generation hybrid LED moving head lighting effect that features a powerful 300w LED engine that provides a huge output making it suitable for large venues and events.

The Vizi CMY300 comes with a motorized focus and zoom which allows for super crisp projections while the two rotating prisms (one 6-facet linear & one 3-facet circular) create unique patterns. There are two GOBO wheels, one of which is removable so you can replace it if required, as well as a colour wheel featuring several colours. The Vizi CMY300 offers CMY colour mixing which allows you to create your own custom colour pallets for a one-of-a-kind light show.

The Vizi CMY300 works as either a beam, spot or wash light and features an enormous zoom that ranges from 8 to 48 degrees which allows you to get the most use from one fixture so you won’t have to use multiple fixtures. The Vizi comes with a smaller footprint than most other moving head effects which allows it to be more efficient.

The front of the lighting effect features an LCD display that allows you to control the lights functions and settings while the rear of the Vizi CMY300 provides a powerCON in/output as well as a 3-pin & 5-pin DMX connections. Under the hood, this lighting effect has a modular design that makes servicing and replacing GOBOs a walk in the park.

Light Source

  • 300W Cool White LED Engine
  • 50,000 Hour Average LED Life

Colour

  • Colour Wheel: 9 + Open (Including: CTO 3200K & UV)
  • Full CMY Colour Mixing

GOBOs

  • GOBO Wheel 1: 8 Fixed + Open (1 Beam Reducers Beam Mode)
  • GOBO Wheel 2: 6 Rotating/Replaceable + Open (Size: 26.8mm; Viewable: 20mm)
  • Modular design for easy servicing and GOBO replacement

Effects

  • Zoom Range: 8 ~ 48-degrees
  • Iris: Motorized 5-100%
  • Focus: Motorized
  • Frost effect
  • Prism 1: Rotating 3-facet Circular
  • Prism 2: Rotating 6-facet Linear Rotating
  • Prism Layering

Connections

  • Power Input: powerCON
  • Power Pass through: powerCON @120V or 220V
  • USB firmware update port

Control

  • Control Channels: 21, 24 or 26
  • DMX Modes: 3
  • Control: 3-pin and 5-pin DMX
  • Full color display menu
  • Pan / Tilt Correction: Automatic
  • Pan / Tilt Lock
  • Pan / Tilt Range: 540˚ / 270˚
  • Fine Tilt
  • Pan/Tilt Speed: Fast to Slow
  • Dimming & Fine Dimming: Electronic

Electrical

  • Input Voltage: 100-240V 50Hz/60Hz (Auto Sensing)
  • Daisy chain max: 4 fixtures (@120V); 8 fixtures (@230V)
  • Power Draw: 398W (3.31A @ 120V; 1.8A @ 220V)

Dimensions

  • Dimensions (LxWxH): 370 x 325 x 619mm
  • Weight: 23 kg.
