IMG Stageline MMX-44 8-Channel Audio Mixer

The IMG Stageline MMX-44 is a high-quality 8-channel audio mixer that comes complete with 12 inputs alongside plenty of professional features such as 48v Phantom Power, an auxiliary send/return channel, adjustable headphone output and stereo LED level indicators that enable you to see when you’re overloading the mixer. This mixer is perfect or small recording studios and production houses as well as home studios so you can capture a plethora of audio sources inside of an intuitive mixer.

The MMX-44 features four monophonic input channels; each channel comes equipped with a gain control, 3-band equaliser, a low-cut function and pan pot. There are also four stereo input channels that are each equipped with a balance control and dedicated volume control. Each channel comes with an adjustable auxiliary send/return rotary control so you can apply FX using an external effects processor if required; each channel also features a 48v Phantom Power supply so you can power your microphones if needs be.

There is a tape record/play function that allows you to route the primary signal to the main mix or to the booth and headphone output. The stereo master output connections consist of two unbalanced ¼-inch TRS Jack, and there are LED indicators that allow you to see if you’re overloading the main output and a master volume fader lets you control the overall volume.

IMG Stageline MMX-44 8-Channel Audio Mixer Key Features:

• 8-channel audio mixer with 12 inputs.
• 4 mono input channels, each with gain control, 3-way equalizer, low cut and pan pot
• 4 stereo input channels, each with balance control
• Adjustable aux send output
• Control room function
• Tape record/play connections
• +48 V phantom power, can be switched centrally
• Adjustable headphone output
• Stereo LED level display
• Power is provided via enclosed power supply

IMG Stageline MMX-44 8-Channel Audio Mixer Technical Specifications:

• No. of channels: 8
• No. of inputs: 12
• Mic input: 0.5 mV, bal., 4 x 3-pole XLR
• Line input: 10 mV, bal. (stereo), 4 x 6.3 mm jack L/R, 1 mV (mono), 4 x 6.3 mm jack
• Tape (play): 100 mV, 1 x RCA L/R
• Master output: 650 mV, 1 x 6.3 mm jack L/R
• Aux output: 9.5 V, 1 x 6.3 mm jack
• Control room: 2 V, 1 x 6.3 mm jack L/R
• Tape (rec): 650 mV, 1 x RCA L/R
• Headphones: ≥ 8 Ω, 1 x 3.6 mm jack
• Frequency range: 20-20,000 Hz
• THD: < 0.05%
• S/N ratio: > 74 dB
• Crosstalk: -63 dB
• Equalizer bass: ±15 dB/80 Hz
• Equalizer midrange: ±15 dB/2.5 kHz
• Equalizer treble: ±15 dB/12 kHz
• Phantom power: +48 V
• Power supply: via encl. power supply
• Admiss. ambient temp.: 0-40 °C
• Width: 280mm
• Height: 50mm
• Depth: 260mm
• Weight: 2.2kg
