Mackie Mix5 5-channel Compact Mixer

Mackie Mix5 5-channel Compact Mixer The Mix5 5-channel compact mixer is reliably rugged, with the proven quality you expect from Mackie, the world leader in compact mixer design. Perfect for straightforward applications that incorporate a single mic with other sources, Mix5 sounds great and maintains audio quality from any source. Plus, with a rugged metal chassis and high-quality components throughout, Mix5 is a solid investment in reliability. An amazing value, Mix5 is extremely easy to use and delivers the sound quality you need in a rugged design built to last. Plus, wouldn’t you rather mix on a Mackie? Don’t sacrifice – choose the Mackie Mix Series.

Mackie Mix5 5-channel Compact Mixer Features:

•  5-channel compact mixer with proven high-headroom, low-noise performance
• 1 mic/line input with studio-level audio quality
• 2-band EQ with clean, precise tone shaping
• Phantom power for studio condenser mics
• 2 stereo 1/4" line inputs
• Dedicated stereo RCA inputs/outputs for playback or recording
• Main L/R outputs
• Headphone output with separate volume control
• Rugged, reliable design built to last
• Extremely compact and portable

Noise Characteristics (20Hz-20kHz bandwidth, 150 Ω source impedance)

• All outputs, master levels and channel levels off: -100 dBu
• All outputs, master levels unity, all channel levels off: -90 dBu
• All outputs, master levels unity, 1 channel level unity: -85 dBu

Distortion (THD-N) (1kHz, 20Hz-20kHz bandwidth)

• Mic Input to Main Output: <0.1% @+4 dBu output

Attenuation and Crosstalk (20Hz-20kHz bandwidth)

• Inputs to Outputs @ 1kHz: -85 dB
• Main Mis Off @ 1 kHz: -80 dB

Frequency Response

• Mic input to any output (gain @ unity): +0, -1, 20Hz to 30kHz

Equivalent Input Noise (EIN) (Mix in to Insert Send out, max gain.)

• 150Ω termination: -125 dBu

Common Mode Rejection Ratio (CMRR) (Mic in to Insert Send out, Max gain.)

• 1 kHz: better than 70 dB

Maximum Levels

• Mic inputs (XLR): +18 dBu
• All other inputs: +21 dBu
• All outputs: +21 dBu

Impedances

• Mic in: 2 kΩ
• All other inputs: 10 kΩ or greater
• Tape out: 1 kΩ
• Phones out: 22 Ω
• All other outputs: 120 Ω unbalanced, 240 Ω balanced

EQ

• High Shelving: ±15 dB @ 12kHz
• Mid Peaking: ±15 dB @ 2.5kHz
• Low Shelving: ±15 dB @ 80 Hz
• Low Cut Filter: 18 dB/octave, -3 dB @ 75 Hz

AC Power Requirements

• Input: AC220-230V∼, 50/60 Hz
• Output: (AC9V∼300mA)x2
• Operating Temperature: 0º - 40°C/32°-104°F

Other

• Height: 43 mm / 1.7 in
• Width: 140 mm / 5.5 in
• Depth: 196 mm / 7.7 in
• Weight: 0.6 kg / 1.4 lb
